Overview |
|||||||||
      |
|||||||||
|
Enhanced Reliability for Industrial Networks
The PLANET ISW-1033MT Managed Industrial Ethernet Switch is equipped with multiple redundant ring technology and provides 7 10/100Mbps Fast Ethernet, 3 Gigabit TP/SFP combo interfaces and 2 DI/DO delivered in a rugged strong case. It is an industrially (substation) hardened and fully managed with Ethernet Switch specifically designed to operate reliably in electrically harsh, climatically demanding, wide temperature range (-40℃ to 75℃) and centralised power management environments. The ISW-1033MT is the most reliable choice for highly-managed and Fibre Ethernet application. • 3 Gigabit / Fibre uplink capability • 2 DI/DO for event and alarm • Redundant Ethernet Network • Industrial Protect 30 Metal Case • Manageable • Power Redundant • Wide Temperature Support Fast Recovery to a Redundant Ethernet Network The ISW-1033MT features strong and rapid self-recovery capability to prevent interruptions of industrial network operation and external intrusions. It incorporates advanced redundant data Ring technology, Rapid Spanning Protocol (IEEE 802.1w RSTP) and redundant power supply system into customers’ industrial automation network to enhance system reliability and uptime in the harsh factory environments. It also protects customer’s industrial network connectivity with switching recovery capability that is used for implementing fault tolerant ring and mesh network architectures. If the Industrial network was interrupted accidentally, the fault recovery times could be less than 20ms to quickly bring the network back to normal operation. Tough, Environmentally Hardened Design With IP-30 aluminium industrial case protection, the ISW-1033MT provides a high level of immunity against electromagnetic interference and heavy electrical surges which are usually found on plant floors or in curb side traffic control cabinets. The ISW-1033MT also provides a wide range of power supply options suitable for multiple industries and for worldwide operation. The feature of operating temperature range from -40 to 75 Degree C allows the Managed Industrial Switch to be placed in almost any difficult environment. Robust Layer 2 Features and Advanced Security The ISW-1033MT supports robust advanced features including IEEE 802.1Q VLAN, GVRP, Port link aggregation, QoS, broadcast storm control, MAC address filtering, IGMP snooping enhanced security and bandwidth utilization to fit a variety of applications. Via aggregation of supporting port, the ISW-1033MT allows the operation of high-speed trunk combining multiple ports. Maximum up to 4 ports of the ISW-1033MT can be assigned for 4 trunk groups and support fail-over as well. Additionally, its standard-compliant implementation ensures interoperability with equipment from other vendors. Efficient and Centralized Management The ISW-1033MT provides the benefit of efficient and centralized management with the built-in console, WEB and SNMP management interfaces. The Web-based management of the ISW-1033MT is an easy-to-use, platform-independent management and configuration facility supporting standard Simple Network Management Protocol (SNMP) and can be managed via any standard-based network management system. For text-based management, the ISW-1033MT can be accessed via Telnet and the console port. The enhanced system reliability and advanced networking features offered by the ISW-1033MT makes it ideally suited to build the Industrial Ethernet networks for mission-critical and real-time control applications. Flexibility and Extension Solution The three mini-GBIC slots in the ISW-1033MT are compatible with 1000Base-SX/LX/WDM and 100Base-FX through SFP (Small Form Factor Pluggable) fibre-optic transceivers. The fibre optical uplink capability guarantees the throughput to all nodes hooked into the network and the Gigabit Ethernet distance can be extended from 550 meters (Multi-Mode fibre cable) up to 10/20/30/40/50/70/120 kilometres (Single-Mode fibre or WDM fibre). They are well suited for applications within the factory data centres and distributions. Easy Installation The ISW-1033MT is packaged in a compact case that allows either DIN rail or panel mounting for efficient usage of cabinet space. It provides an integrated power supply with a wide range of voltages for worldwide operation. It also offers dual-redundant, reversible polarity 12-48V DC power supply inputs for high availability applications requiring dual or backup power inputs. |
|||||||||
